| Parameter | Specification |
|---|---|
| Measuring range | 1-10 bar |
| Thread size | G 1/4 |
| Accuracy at 25°C (Linearity, hysteresis, repeatability) |
≤ ±0.25% FS (typical) ≤ ±0.1% FS (on request), at 25°C (including unevenness, repeatability and hysteresis) |
| Long-term stability | 0.1% FS per year |
| Working temperature |
-20°C ~ 80°C (corrosive medium) -40°C ~ 80°C (non-corrosive medium) |
| Storage temperature |
-40°C ~ 125°C (nitrile rubber O-ring) -30°C ~ 150°C (fluoro rubber sealing ring) |
| Water resistance | IP65 to IP67 |
| Reaction time | ≤10ms |
